2026 Ford F550 w/1302E-13/46P (WR203)

2026 Ford F550

• 4×2
• 108″CA/193″ WB
• 19500# GVW
• 6.7L Diesel
• Automatic
• Air Conditioning
• Cruise Control
• Tilt Wheel
• AM/FM
• Cab Steps
• 40/20/40
• Vinyl Seat
• Sync System
• Power Group
• Backup Camera

Body

• 1302E – Mini-OTR
• Aluminum Body
• Rack Sides
• 13’L, 36″H
• (2) Front Vertical Compartments 64″H x 22″D x 26″W
• Hose Reels On CS Of Body
• 12″ Low-Profile Rear Gate Between Vertical Compartments
• LR And RR Underbody Compartments 19″H x 29″W x 22″D
• Stop, Turn, Tail-Light Kit
• Single Skirt-Mounted Lights RS/LS
• Dual Fuel Fills

Equipment / Options

• Crane Installation Kit
• Mini-OTR Bead Hook
• 12000# Capacity
• Small Tire Crane Remote Docking Station Kit
• Service Kit For Stellar 46P Compressor and 3200/4500/6000 Crane
• 2,000# Hydraulic Liftgate
• 86″ Wide
• Dual Lift Cylinders
• Recessed Lights
• Galvanized Frame And Platform
• Folding Side Rail And Tire Stop For 86″ Wide Liftgate
• Sign Panel for Model 87 Tommy Gate

Air Options

• 1/2” Reel Craft Dual Post Hose Reel
• 50’ Artic Grade Hose
• 1/2″ FLR System (Filter/Lubricator/Regulator)
• Regulator For Lubricated Line
• Easily Replaceable Segments And Safety Air Dump Valve
• 20′ OTR Inflation/Deflation Hose Kit w / Quick Release Coupler For Emergency Air Evacuation
• Includes Muffler
• Small And Large Bore Core Ejectors
• 1/4 Turn Ball Valve And Rotary Air Gauge For Checking Tire Pressure

Tool Package

• Tire Bead Wedge – Six Pack

Compartment Options

• Plastic Tray Package
• (4) 5″ W Trays & (6) 3 1/2″W Trays For LF Or RF Vertical Compartment
• 15-Pin Socket Rack
• Drawer Set
• 8″H x 18″W x 18″D
• 2-3″ (Hanging)
• Adjustable Shelf

Jackbox Option

• Underbody Toolbox Panel

Body Mounted Options

• Dri Deck Mat Kit For Compartment Floors
• Aluminum Folding Step
• One Pair Stellar Mud Flaps With Mounting Bolts – Factory Installation
• 25-Gallon Tire Life Tank Mounted In Loadbed
• Two Bar Truck Tire Safety Inflation Cage
• Inflation Cage Holder (Body Deck Mount)
• LED Flood Light With Wide Beam
• Compartment LED Light Kit
• Works With Electric Control Switch
• Whelen Century 16″ LED Amber Mini Lightbar With Clear Lens And Mount Kit
• Streamlight Stinger Switchblade LED Work Light With J-Hook, Magnetic Base, UV Light For Leak Detection
• 180 Degrees Of Rotation, Includes Charger
• Strobe Light Kit – Low Profile LED Amber Lights
• (2) Mounted In Chassis Grill
• Strobe Light Kit – Low Profile LED Amber Lights
• (2) Mounted On Rear Truck Surface
• Two Tire Carrier Mast Mounted LED Floodlights
• Rear Ground Perimeter Light

Safety Options

• Chassis Mounted Back Up Alarm – 107 Db
• Ford Chassis Provided Backup Camera
• ICC safety kit consisting of rechargeable 2.5# fire
  extinguisher and reflector kit – Installed

PTO/Pump Options

• PTO For Automatic Transmission
• Hydraulic Pump, Tandem Section For Crane And Compressor

Includes:

• 112630X PTO 210FMMFP-B4AD 2020 FORD DIESEL 10
• SP 4X4 ONLY INST
• 95665 PUMP HYD
• DE2L-38SC-AA-126-14-N732-NNN-000-XX-AN-NNN
• 107170X PUMP INSTALL KIT TANDEM TIRE

Electrical Options

• Speed control kit – Includes Start-Stop Functionality
• Electrical Control Kit – Includes Harness
• Upfitter Switches ONLY

Paint & Finish

• • Paint 902/1302E Body Stellar White
  • Axalta Paint Code 350407EX
  • Single Stage, Non-Metallic

Stellar 46P Hydraulic Driven Compressor

• Produces 46 CFM @175 PSI
• 4 Cylinder
• 2 Stage Industrial Compressor
• Directdrive Coupling
• Hydraulic Motor
• Oil Cooler
• Fan
• Steel Base Plate
• Fittings
• Filter
• 15 Gal. Hyd. Reservoir
• 20 Gal. Air Tank
• Service Kit For Stellar 46P Compressor
