ECCR Container Carrier Truck
Extendable Carrier with Rotation
Placement, pickup and dumping is quick, smooth and simple with the Stellar® ECCR Container Carrier Truck. It has an extendable and retractable fork body, making it easy to adjust to varying container locations. The hydraulic 360-degree continuous rotator makes dumping easier, too, letting you dump front-load containers in either direction of rotation.
PrintAdditional Information
ECCR Container Carrier Trucks are built with top-quality materials and precision assembly by Stellar’s experienced team. Each ECCR is engineered for superior weight distribution for smooth performance and reduced wear. The center of gravity is located approximately 9.25″ in front of the rear axle. In the stored position, the center of gravity of the container is approximately 45″ behind the rear axle. Maintenance is simplified through the streamlined design with fewer wear items to take care of, and the rear lights improve visibility.
The carrier can handle both front-loading and rear-loading dumpster containers up to 8,000 lbs. Add in the precision control of the extendable body and rotation system, and the ECCR Container Carrier Truck is the efficient, productive choice for placement, hauling and pickup of waste, recycling and scrap dumpsters.
Still more versatility: The ECCR can also be mounted on Stellar’s Shuttle16 (Flex) Hooklift, extending its dumpster-hauling capabilities.
Specifications
| Lifting capacity: | 8,000 lbs (3,629 kg) |
| Dumping capacity:* | 8,000 lbs (3,629 kg) |
| Transporting capacity:** | 8,000 lbs (3,629 kg) |
| Container sizes: | 2 – 10 cubic yds |
| Type of containers: | Front and rear load |
| Rotation: | Worm/turntable gear bearings |
| Stacking capability: | 2 – 8 cubic yds |
| Operating pressure: | 4,500 psi (31 mpa) |
| GPM: | 12 (45 lpm) |
| Hydraulic tank: | 10 gal (38 ltr) |
| Recommended CA: | 84" to 114" (2,134 to 2,896 mm) |
| Controls: | Inside and outside |
| Bushings and zerks: | All pivot and rotation points |
| Container bumpers: | Molded rubber |
| Hydraulic pump: | Bent axis piston type |
| Valve bank: | 4-spool cable controlled |
| Min. chassis GVW: | 26,000 lbs (11.8 mt) |
| C/L of gravity: | 9.25" forward of rear axle |
| C/L of payload: | 45" behind rear axle |
| Shipping weight: | 3,300 lbs (1,497 kg) |
