LM120 Lube Skid
Instantly add convenience and flexibility to your fleet. Outfit your service truck with the LM120 Lube Skid, available in both mobile and permanent-mount models, for the capacity to handle lube and preventive maintenance services onsite. Hardware to mount and plumb is included. A lighter-weight aluminum model is available for higher truck payload, and you can also get configurations for service vans.
PrintSpecifications
- Mobile and permanent models available
- Two (2) 40-gallon new oil tanks internally baffled with sight gauges and vented caps
- 49-gallon waste oil tank internally baffled with dipstick and vented cap
- Two (2) 5:1 pumps with reliefs for new oil
- 1″ diaphragm pump with 4-way valve for evacuation and discharge of waste oil tank
- Two (2) 1/2″ x 50′ new oil reels with mechanical meters
- 1″ x 25′ waste oil reel with quick coupler
- 3″ x 6″ forklift sleeves with D-ring tie-downs (mobile only)
- Optional 35-lb or 120-lb grease kit
- Drip pans and cabinets available for permanent models
- 7-gallon drain pan with quick coupler and stub, and connecting hoses
- Dimensions: 47.5″W x 38″T x 33″D
