LM200 Lube Skid
Add efficiency to your operation when you add lube truck services to your service truck. The LM200 Lube Skid, available in both mobile and permanent-mount models, gives you the capacity to handle preventive maintenance onsite to get equipment back on the job fast. It comes complete with hardware to mount and plumb. A lighter-weight aluminum model is available for higher truck payload, and you can also get configurations for service vans.
PrintSpecifications
- Mobile and permanent models available
- Three (3) 40-gallon new oil tanks internally baffled with sight gauges and vented caps
- 80-gallon waste oil tank internally baffled with sight gauge and vented cap
- Three (3) 5:1 pumps with reliefs for new oil
- 1″ diaphragm pump with 4-way valve for evacuation and discharge of waste oil tank
- Three (3) 1/2″ x 50′ new oil reels with mechanical meters
- 1″ x 25′ waste oil reel with quick coupler
- 3″ x 6″ forklift sleeves with D-ring tie-downs (mobile only)
- Optional 35-lb or 120-lb grease kit
- Drip pans and cabinets available for permanent models
- 7-gallon drain pan with quick coupler and stub, and connecting hoses
- Dimensions: 47.5″W x 46″T x 39″D
