Stock: 2026 TMAX 1-11 Aluminum

Body

• 2025 TMAX1-11 Aluminum Mechanic Body
• Aluminum Side Packs
• Aluminum Doors
• Isolated Steel Crane Compartment
• Torsion Box Understructure
• All Compartments Raised To 52″
• 8″ Drop Well In CS1V For Oxy / Acet Bottles
• 21″ Work Bench Bumper With Thru Compartment
• Flush Front Bulkhead
• Exterior DOT Light Package
• Master-Lock System
• 22″D X 52″H Side Packs
• 133″ Long
• (6) Recessed Cargo Tie-Downs
• Dual-Seal Automotive Type Compartment Weather Seal
• Rubber Fenderettes
• Overlapped Doors On SS1V / CS1V And Horizontal Compartments
• 2 & 3-Point Stainless Steel Compression Latches
• Stainless Steel “Billet Style” Hinges
• Spring Loaded Door Stops
• Weld On Receiver Hitch
• Prime, Painted, Undercoated

Air Options

• FLR Strut Mounted System – 1 Outlet For Air Hose (Filter, Lubricator, Regulator)

Hydraulic Options

• Hydraulic Reservoir – 20-Gallon
• Bulkhead Mounted
• Painted Black
• Heavy Duty Aluminum Bale Style Pull Handle Drawer Set
• 35.5″H x 31″W x 18″D, 3-3″, 3-5″, 1-7″ (Incl. 2.5″ Riser)
• Drawer LightBar For Use On 30″ Wide Drawers With A Left-Hand Wire Harness
• SS1VR Strut Mounted Shelf With (3) Dividers 18.50″W x 19.00″D
• SS Horizontal Heavy Duty Aluminum Bale Style Pull Handle Drawer Set
• 13.5″H x 48″W x 18″D, 3-3″ (Incl. 2.5″ Riser)
• Drawer LightBar For Use On 48″ Wide Drawers With A Lefthand Wire Harness
• SS Rear Strut Mounted Shelf With (3) Dividers 23.38″W x 19.00″D
• CS1V Divider Kit With Strut Mounted Shelves
• 19.00 Wide For Oxy/Acet In Curb Side 52″ And 60″ Compartments
• Strut Mounted Oxy-Acet Bottle Holder – 2 Bottle Holder
• CS2V Strut Mounted Shelf With (3) Dividers 20.38″W x 19.00″D
• CS Horizontal Strut Mounted Shelf With (3) Dividers 52.00″W x 19.00″D
• CS Rear 1/2″ x 50′ Hose Reel With Roller Guide – Exits Rear Of Body

Body Mounted Options

• Rock Guard Kit – Adhesive Black
• Black Grab Handle – Mounts To Rear Side Pack And Bumper
• One Pair Stellar Mud Flaps
• TMAX Aluminum Tailgate – 12″ Tall, Painted Black
• Adjustable Boom Support – Octagon Booms – 21.5″ to 27.5″
• TMAX Aluminum Body – Roller Rest – Painted Black

Bumper Mounted Options

• Vise Mounting Plate – Receiver Work Bench Mount
• Slide Out Step For TMAX Work Bench Bumper
• Aluminum Stabilizer Assembly – Hydraulic Out/Hydraulic Down For Installation In Bumper
• Painted Black

Light Options

• LED Flood Light For TMAX Aluminum Body
• LED Compartment Light Kit
• Stellar® Rear Taillights
• Sequential Turn Signals
• Integrated Strobe Lights
• License Plate Bracket
• ID Light Bar
• One Flood Light Mounted On Top Of Each Taillight

Safety Options

• Cover Plate For Backup Camera

Electrical Options

• Truck Upfitter Switches Control Package

Paint & Finish

• Stellar White Paint, Axalta Paint Code
• Spray On Bed Liner For Load Bed Walls And Floor – Black
• Spray On Bed Liner For Work Bench Bumper – Black

8630

• Crane Rating : 77,800 ft-lb
• Max Lifting Capacity: 12,000 lbs @ 6′ 5″
• Maximum Horizontal Reach: 30′ from CL Of Crane
• Maximum Vertical Lift: 31′ 9″ From Crane Base
• Boom Elevation: -10° to +80°
• CDTpro™ Control System w/Range Finder

40P Hydraulic Driven Air Compressor

• 40 CFM @ 100 PSI
• 2-Cylinder Single Stage Compressor
• Direct Drive Coupling
• Oil Cooler, Fan, And Hydraulic Motor
• Includes Steel Base, Enclosure, And A Flip Up Lid
• Dimensions: 31.5”L x 20”W x 23.5”H
• Weight: 300 lbs (Dry).
