2027 Peterbilt 536 w/TM4110/9000/46P (WR176)

2027 Peterbilt 536

• 144″ CA/212″ WB
• 26,000# GVW
• Paccar PX-7 300 HP Diesel
• Allison 2500
• 12,000# Front Axle
• 19,000# Rear Axle
• Horiz. Exhaust With Vertical Pipe
• Air Brakes
• 50-Gallon LH Fuel Tank
• 11R22.5 Tires
• Air Cond.
• Air Cushion Driver’s Seat

Body

• 138-215 Steel Flatbed Body
• 15’L, 3/16″ Deck Plate Floor
• Upper Reel And Storage Compartment 34″H x 30″W x 27″D
• Lower Compartment 30″H x 30″W x 27″D
• CS1V Compartment 64″H x 30″W x 20″D
• Underbody Tool Compartments
• 12 D-Rings In The Load Bed
• Stop, Turn, Taillights – Body Mounting Kit

Equipment / Options

• Swivel Load Hook
• 9000 Crane Service Kit
• Stellar 46P Air Compressor

Air Options

• 1/2” Reel Craft Dual Post Hose Reel With 50’ Artic Grade Hose
• Channel Mounting In Compartment
• 22-Gallon Air Tank – ASME Approved
• Fittings And Hose Kit
  • 1/2″ FLR System With Additional Regulator For Lubricated Line
  • Easily Replaceable Segments And Safety Air Dump Valve
  • 20′ OTR Inflation/Deflation Hose Kit W/ Quick Release Coupler For Emergency Air Evacuation
  • Small And Large Bore Core Ejectors And 1/4 Turn Ball Valve And Rotary Air Gauge For Checking Tire Pressure

Tool Package

• Six Tire Bead Wedge Pack

Compartment Options

• 3 1/2″ Wide Plastic Tray Inserts
• 5″ Wide Plastic Tray Inserts
• 10.5″H x 32″W x 16″D, 2-3″
• Adjustable Shelf – 17″D x 30″

Front Compartment Options

• Adjustable Shelf – 13″D x 45″ W

Rear Compartment Options

• Adjustable Shelf – 13″D x 45″ W

Body Mounted Options

• Dri Deck Mat Kit
• Compartment Sill Guards
• Stellar Mud Flaps
• 25-Gallon Tire Life Tank – Mounted In Load bed

Bumper Options

• Frame Mounted Heavy Duty Rear Bumper/Block Storage Box
• 94″W x 24″H x 19″D
• Vertical Taillights W/ Cover Kit
• LED Flood Light W/ Wide Beam
• Large OTR LED Compartment Light Kit – Front Vertical And Underbody Tool Box Compartments
• Amber LED Beacon Light
• High Mount Light Kit
• Streamlight Stinger Switchblade LED Work Light
• UV Light For Leak Detection – 180 Degrees Of Rotation
• Strobe Light Kit – Low Profile LED Amber Lights
• Carrier Mast Mounted LED Floodlights

Safety Options

• Chassis Mounted Back Up Alarm – 107 Db
• ICC Safety Kit
  • Rechargeable 2.5# Fire Extinguisher
  • Reflector Kit

Electrical Options

• Program Speed Control
• Electrical Control Kit – Includes Harness And Switch Panel With 12V Power Port

Paint & Finish

• Paint 15′ OTR body Stellar White – Includes Undercoating
• Non-Metallic
• Spray On Bed Liner – Black

Stellar Model 9000 Crane

• 16′ Of Reach From Center Line Of Chassis
• 90,000 ft-lb Capacity
• 9,000 lbs. @ 10′
• 5,425 lbs. @16’7″
• Fully Proportional Radio Remote Control
• Counterbalance Check Valves
• Dual Worm Gear Rotation
• Fold Over Style Stabilizers
• Painted White

Stellar Accessories

• 46P Compressor
• 30-Gallon Hydraulic Reservoir
• 46 CFM @175 PSI
• With Base, Motor, Cooler, Filters And Fittings

Stellar Model TM4110 Tire Manipulator

• Parallelogram Arms
• 4600 lbs. Lifting Capacity
• 300° Of Body Rotation
• 154° Angle Of Articulation
• 90° Rotating Pads
• Clamping Span Of 16″ To 110″
• Painted White

Stellar Accessories 46P compressor

• 30-Gallon Hydraulic Reservoir
• Crane Mounted
• 46 CFM @175 PSI With Base, Motor, Cooler, Filters And Fitting
