65R ROTARY SCREW AIR COMPRESSOR

Durability Standard

• The rotary screw compressor air-end is oil-injected to eliminate metal-to-metal contact of the two compressor screw lobes.
• The result is an air compressor designed for 100% continuous-duty cycle with extremely long life.
• The rotary screw compressor air-end is belt-driven by a heavy-duty hydraulic motor for reliable service.
• Oil/water separation system and oil filtration of the compressor for long life.
• System includes a dual-purpose, integral cooler for both the compressor oil and the truck’s hydraulic oil. For most applications, this eliminates the need for a separate hydraulic oil cooler, saving you money.
• For safety and reliability, the system includes a pressure relief valve, minimum pressure/check valve, automatic air pressure relief upon shutdown and a safety relief.

Ease of Use

• Bulkhead fittings for quick and simplified hookup. Hydraulic supply lines, return lines and electric power supply connector are all located at one end of the compressor enclosure.
• Includes an attractive powder-coated steel enclosure with a flip-up lid and pneumatic hold-open for easy access to all maintenance points.
• Enclosure also includes easy-to-read temperature gauge and hour meter. A resettable safety relay is also conveniently located on the outside of the enclosure.
• Oil level check/refilling is simplified by access from outside the unit.
• Automotive-type air cleaner for high capacity and long life.
