SI-30/40 Cable Hoist Truck
30,000- or 40,000-lb Capacity
Get job after job after job done with the Stellar® SI-30/40 Cable Hoist Truck. It has the power and smooth performance to maximize productivity on a daily basis. Choose from the SI-30 for a 30,000-lb hoist rated capacity for a single rear axle chassis or the SI-40 for a 40,000-lb hoist rated capacity for a tandem rear axle chassis.
Additional Information
- Reeving Cylinder Enclosure to reduce exposure from damaging debris.
- Dump Cylinder Mounting above and outside of the frame rails for easier access and stability during dumping.
- Durable Construction includes zinc-plated steel pins in the rear hinge, sheaves and cylinders, plus 1/2″ high-strength wear plates at the end of the main frame tubes.
- Cable Routed in the single direction of rotation.
- Flexibility to mount to a single axle chassis with the capability of being built with drop axle.
- Improved Maneuverability when installed on single rear axle chassis.
- Container Lock is automatic spring loaded.
- Gear-Type Hydraulic Pump for 25 gpm and low pressure.
- Counterbalance Valves prevent cylinder movement in case of pressure loss.
- Protective Coating featuring two-part polyurethane automotive finish paint for added protection against scratches and debris.
- Easy Maintenance thanks to greaseable bushings with zerks at all pivot points.
Warranty:
- 36 months structural
- 12 months parts and labor
Specifications
| Hoist Rated Capacity: | 30,000 lbs for single rear axle chassis |
| 40,000 lbs for tandem rear axle chassis | |
| Main Frame: | 8" x 4" x 3/8" A500 C tubing |
| Subframe: | 4" x 2" x 1/4" A500 C tubing |
| Front Stop: | 1-1/2" plate |
| Container Lock: | Automatic spring-loaded |
| Lift Cylinder Shaft: | 2-1/2" solid steel |
| Rear Hinge Shaft: | 2" solid steel |
| Cable: | 7/8" (6 x 37 EXIWRC) |
| Cable Sheaves: | 10" O.D. bronze-brushed sheave |
| Cable Anchor: | 4 cable clamps |
| Cable End: | Steel casting |
| Lift Cylinders: | 5" x 72" D.A. |
| Reeving Cylinder: | 5" x 80" D.A. |
| Operating Pressure: | 30,000 lbs capacity: - 2,000 psi (main cylinders) - 2,500 psi (reeving cylinders) 40,000 lbs capacity: - 2,500 psi (main cylinders) - 3,000 psi (reeving cylinders) |
| Hydraulic Valve: | 2-spool 25 gpm |
| Hydraulic Reservoir: | 25-gal 10-micron filter & screen filter |
| Outside Rollers: | 4" O.D. with bronze bearing |
| Working Points: | Greaseable |
| Safety Stand: | Factory-installed |
| I.C.C. Bumper: | Folding, mounting lugs factory-installed |
| Rear Bumper: | Pre-drilled bolt mount — sealed beam backup, clearance and tail lights |
| Hoist-Up Alarm: | Alerts operator that dump is in elevated position |
| Cable End: | Steel casting, knuckle type |
| Rear Flange Roller: | 8" O.D. hardened with 2-1/2" c-1045 |
| Hoist Up: | 34 sec. approx. |
| Hoist Down: | 26 sec. approx. |
| Cable In: | 32 sec. approx. |
| Container Length: | 18' – 22' |
| Approximate Weight: | 4,950 lbs |
Optional Equipment
| Inside Controls: | Pneumatic |
| Auxiliary Fold-Down Front Stops: | For short containers |
| Full Fenders: | Tandem or tri-axle, 12-gauge steel or poly |
| Tarp Rack/Toolbox Combination: | 20" x 16" x 48" |
| Rear Hold Down: | 1" plate located for standard containers |
| Middle Hold Down: | 3/4" plate |
| Hydraulic Valve: | 3-spool 25 gpm |
| 4-spool 25 gpm | |
| Drop-In Stops: | For short containers |
| Lift Cylinder: | Boxed-beam double-shear lift cylinder with replaceable stub pins and cross tube for hose routing |
| Air-Operated PTO: | For use with manual transmission chassis |
| Hot-Shift PTO: | For use with automatic transmission chassis |
| Single-acting hydraulic line to rear*: | Hydraulic function to rear of container |
| Double-acting hydraulic line to rear*: | Hydraulic function to rear of container |
| Double-acting hydraulic line to side*: | Hydraulic function to rear of container |
| *Requires the 3-spool valve option or selector valve. | |
| Also available: | |
| Cab Guard |
